Add-On GPS 3000/3050/3100 General Instructions
Ag Leader Technology
June 2001 Rev. 1 3000124 21
SATELLITE DIFFERENTIAL SETUP
Differential Source WAAS
Differential Provider
Satellite Frequency
0000.0000
Satellite Baud Rate 0000
Provider User Code 0
OMNISTAR Code 000000000000000000000000
Subscription Expiration
00/00/0000
Ag of Differential 90 seconds
EDIT EXIT
Figure 15. Satellite Differential Setup screen.
Diagnostic Screen The diagnostic screen (Figure 16) provides troubleshooting and
reference information for the Add-On GPS. Provided are
definitions of screen terms.
GPS DIAGNOSTICS
UTC TIME
00:00:00
Latitude 0000.0000 S
Longitude 0000.0000 E
Elevation 0 ft
GPS speed 0.0 MPH
Number of satellites 0
Differential Status OFF
Beacon/Sat. Frequency 0.000
Differential SNR 0.0
HDOP/PDOP 0.00/0.00
Antenna/Rcvr Voltage 5.00/13.73
ADD-ON
GPS
FORMAT
CARD
COPY TO
CARD EXIT
Figure 16. GPS Diagnostics Screen
