Add-On GPS 3000/3050/3100 Contents
Ag Leader Technology
June 2001 Rev. 1 3000124 1
Important Notices
Before beginning installation of your Add-On GPS 3000/3050/3100,
please take the time to thoroughly read these instructions. Signal
words (CAUTION, IMPORTANT, and NOTE) are provided to draw
attention to information that is important for the safe/correct
installation and operation of this product.
• CAUTION--will alert you to situations that will impact the
physical safety of you or others.
• IMPORTANT—will alert you to the potential for damage to the
product or loss of data.
• NOTE--will provide you with additional information to simplify a
procedure or clarify a process.
After completing installation of the Add-On GPS we recommend that
you place these instructions in the Options Section of your PF3000
Operator’s Manual to prevent their loss.
To receive upgrade/update information of this product you must send
in or fax the Registration Form. Refer to the Registration Form for
address and fax number.
Item Page
Installing Add-On GPS 2
Updating Operating Program 4
Install Window –Mount PF3000 Bracket 5
Antenna Installation 6
Parts, Tools for Antenna Installation 7
Installing the Antenna Bracket 7
Installing the Antenna 8
Routing the Cable to the Cab 9
General Instructions 10
Overview 10
General Information 10
Beacon Selection 10
Satellite Selection 13
Optional WAAS Selection 20
Diagnostic Screen 21
NMEA Messages 24
GPS Output/Input 24
Troubleshooting 25
Parts List 27
Beacon Information 28
WAAS Information 32
Satellite Information 33
