General Instructions Add-On GPS 3000/3050/3100
Ag Leader Technology
June 2001 Rev. 1 3000124 16
Call the Omnistar subscription number (713-785-5850 in
the USA) and give them the number to the right of the GPS
serial number. Omnistar will then give you a 24-digit code.
Key the code into the right of Omnistar Code (See Figure
10) using up and down arrow keys. Once the code is
entered, press ACCEPT key to send the code to the unit.
Now press EXIT key to return to GPS SETUP screen, press
exit key to return to operating screen. After 30 minutes, the
receiver should start receiving corrections and display a “D”
in the upper right hand corner of the PF3000.
SATELLITE DIFFERENTIAL SETUP
Differential Source Satellite
Differential Provider Omnistar
Satellite Frequency 1554.497000
Satellite Baud Rate 1200
Provider User Code 3466
OMNISTAR Code 000000000000000000000000
Age of Differential
90 seconds
ACCEPT CANCEL
Figure 10.
Age of Differential Age of Differential is the delay setting used to continue logging data if
Beacon or Satellite reception is lost.
Step Action
1 Scroll down to Age of Differential and press EDIT. See
Figure 10.
2 Use the UP or DOWN ARROW keys to set the time.
NOTE: If you are using Trimble firmware below
version 1.50 you will be able to set the delay up to 90
seconds. If you are using version 1.50 or greater the
value may be set as high as 250 seconds.
