8 Firmware Version 5.4
C
ONNECTING THE
S
YSTEM
•
• (A) Display
• (B) RAM Base
• (C) RAM Arm
• (D) Base
• (E) Receiver
• (F) Receiver Cable
• (G) Display Cable
• (H) Power Cable
S
CREEN
I
CON
C
ONVENTIONS
The following control buttons are made available for entering names and calibration values into the
system.
An on-screen Keyboard is made available when
appropriate for use during all setup processes. Press
the keyboard button to access the on-screen text entry
screen.
Symbols
Clear
All
