Part No. 2002831-38 Rev. B 5
Section 3: AutoSwath
™
Control
Setting Defaults
AutoSwath
™ Control Setting Defaults
STEPS ACTION
1 a The default for the Turn-On Look Ahead is set to 1 second. If you need to adjust
the default, press the keyboard button to change this setting. Increasing this
setting causes the boom sections to turn on sooner. Press Accept when finished.
b The default for the Turn-Off Look Ahead is set to 0 seconds. If you need to
adjust the default, press the keyboard button to change this setting. Increasing it
causes the boom section to turn off sooner. Press Accept when finished.
c In the Outside Boundary Option box there is an option to have the booms shut
off outside of the field boundary or to keep swath section unchanged. This
setting should normally be checkmarked to ensure that the booms shut off
outside the boundary.
d Press the Accept button to save your AutoSwath Settings.
Section 4: Auxiliary Input Settings
The Auxiliary Input Settings feature, (also called “Switch Mapping”) allows you to
specify which switch input controls the boom sections of your implement.
Note: If using an Ag Leader foot pedal, set the master switch to External 2.
