Part No. 2002831-38 Rev. B 12
Section 10: Control Settings
Descriptions
Liquid Servo Settings Description
Setting
Name
Default
Setting
Setting Description Setting Characteristics
Valve
Response 1
100%
Determines the speed of
the servo valve when
product control error
exceeds the Response
Threshold setting.
Decreasing the value will cause the servo
valve to run slower.
Valve
Response 2
24%
Determines the speed of
the servo valve when
product control error is
less than the Response
Threshold setting.
Decreasing the value will cause the servo
valve to run slower.
Allowable
Error
2%
Determines the percent of
error that is allowed prior
to the product control
system making any flow
rate corrections.
2%-3% is the normal dead band setting range.
-Too low of a setting value can cause the
product control system to continually hunt for
the target application rate.
-Too high of a setting will cause excessive
product application error.
Response
Threshold
3
Determines where the
control system switches
between using Valve
Response 1 or Valve
Response 2 speed setting.
Leaving all other valve control settings at the
default value and making a small adjustment
to this setting is usually all that is required to
fine-tune system performance.
-Decreasing this value will have the overall
effect of speeding up servo valve response.
-Increasing this value will have the overall
effect of slowing servo valve response.
