Table 35 LDEV capacity information for each emulation type
Control information
area capacity
Base data area capacity
Minimum data area capacity
Emulation type
cylinders
blocks
cylinders
blocks
cylinders
blocks
7
10,080
3,339
4,808,160
50
72,000
3380-3
7
10,080
3,339
4,808,160
50
72,000
3380-3A
7
10,080
3,339
4,808,160
50
72,000
3380-3B
7
10,080
3,339
4,808,160
50
72,000
3380-3C
7
10,080
2,655
3,823,200
50
72,000
3380-K
7
10,080
2,655
3,823,200
50
72,000
3380-KA
7
10,080
2,655
3,823,200
50
72,000
3380-KB
7
10,080
2,655
3,823,200
50
72,000
3380-KC
6
10,440
3,339
5,809,860
50
87,000
3390-3
6
10,440
3,339
5,809,860
50
87,000
3390-3A
6
10,440
3,339
5,809,860
50
87,000
3390-3B
6
10,440
3,339
5,809,860
50
87,000
3390-3C
6
10,440
3,339
5,809,860
50
87,000
3390-3R
25
43,500
10,017
17,429,580
50
87,000
3390-9
25
43,500
10,017
17,429,580
50
87,000
3390-9A
25
43,500
10,017
17,429,580
50
87,000
3390-9B
25
43,500
10,017
17,429,580
50
87,000
3390-9C
23
40,020
32,760
57,002,400
50
87,000
3390-L
23
40,020
32,760
57,002,400
50
87,000
3390-LA
23
40,020
32,760
57,002,400
50
87,000
3390-LB
23
40,020
32,760
57,002,400
50
87,000
3390-LC
53
92,220
65,520
114,004,800
50
87,000
3390-M
53
92,220
65,520
114,004,800
50
87,000
3390-MA
53
92,220
65,520
114,004,800
50
87,000
3390-MB
53
92,220
65,520
114,004,800
50
87,000
3390-MC
—
11,520
—
4,806,720
—
72,000
OPEN-3
—
38,880
—
14,351,040
—
72,000
OPEN-8
—
38,880
—
14,423,040
—
72,000
OPEN-9
—
27,360
—
28,452,960
—
72,000
OPEN-E
—
10,080
—
71,192,160
—
71,192,160
OPEN-L
—
0
—
–
—
96,000
OPEN-V
lists the base LDEV capacity, minimum LDEV capacity, maximum external LU
capacity, and number of LDEVs that can be defined for the external LU with maximum capacity.
For the OPEN-L emulation type, the base LDEV capacity and the minimum LDEV capacity are the
same because CVs cannot be created. For the OPEN-V emulation type, the base LDEV capacity
is not listed because there is no concept of the base LDEV capacity.
