To access the Status/Information menu:
1.
From the Home screen, press Previous or Next until the screen displays Status/Information.
Press Enter to select.
2.
Press Previous or Next until the screen displays your selected function. Press Enter to select.
Inventory
This option provides information on which slots have cartridges and which are empty. The second
line on the screen display will indicate:
•
Full
•
Empty
The autoloader has the following inventory locations:
•
Left magazine
•
Right magazine
•
Drive
Each location has different information as described below.
For the left or right magazine, the screen display may read, Left Magazine, or Right Magazine.
The second line on the display indicates which slots have a cartridge or are empty. Slots in the left
magazine are numbered 1-5 and slots in the right magazine are numbered 6-10. Each slot is represented
by either its number, a D or _. See
for definitions.
Table 10 Display indication definitions
Character displayed
Definition
Slot
_
Slot is empty
D
The cartridge that was in that slot is now in the drive
!
Media needs attention, often as a result of a damaged or incompatible cartridge
C
Cleaning cartridge, this will only be identified after the cartridge has been
loaded in the drive at least once
F
Firmware cartridge
For example:
1-_-3-C-5
The left magazine has data cartridges in slots 1, 3 and 5. Slot 2 is empty and
slot 4 has a cleaning cartridge.
6-D-8-9-10
The right magazine is full and the cartridge from slot 7 is now in the drive
To view more details about each slot, press Enter when the screen displays either Left Magazine,
or Right Magazine.
To check inventory, do the following:
1.
From the Home screen, press Previous or Next until the screen displays Status/Information.
Press Enter to select.
2.
Press Previous or Next until the screen displays Inventory. Press Enter to select.
3.
By using Previous or Next, you can select from the following inventory locations:
• Left
magazine
• Right magazine
• Drive
