Available Pool Volumes table

Description

Item

Shows the LDEV ID.

LDEV ID

Shows the LDEV name.

LDEV Name

Shows the pool-VOL capacity.

Capacity

Shows the parity group ID.

Parity Group ID

Shows the RAID level.

RAID Level

Shows the hard disk drive type and rpm.

Drive Type/RPM

Shows the emulation type.

Emulation Type

Shows the LDEV type.

Provisioning Type

Shows CLPR.

CLPR

Shows whether the cache mode is enabled or disabled. For a volume other than
external volumes, a hyphen (-) is displayed.

Cache Mode

Add button

If you select a line in the Available Pool Volumes table and then click this button, the selected
pool-VOL is added to the Selected pool volumes table.

NOTE:

The pool-VOL that is first added to the Selected pool volumes table will be the top pool-VOL.

Remove button

If you select a line in the Selected pool volumes table and then click this button, the selected LDEV
is removed from the Selected pool volumes table.

Select Pool Volumes window

91
