Descriptions Items
P-VOL LDKC number, CU number, and LDEV number P-VOL
P-VOL emulation type Emulation
P-VOL capacity in megabytes (MB). Capacity(MB)
P-VOL’s number of blocks (blocks). Capacity(blocks)
P-VOL cache logical partition (CLPR) CLPR(P)
Pool ID of the pool in which the P-VOL is registered Pool ID
Amount of the pool capacity used by the P-VOL Amount of pool used by
P-VOL(GB)
Pool usage rate of the P-VOL Pool usage rate by P-VOL
Snapshot Pair Detail list •
MU: Snapshot ID
• S-VOL: LDKC number, CU number, and LDEV number
•
Status: Pair’s status
• Date: time when the Snapshot data was stored in the pool
•
Pool used(GB): capacity of the pool used by the S-VOL
• Sync.: consistency rate of data of the P-VOL and the S-VOL
•
CLPR(S): S-VOL’s cache logical partition (CLPR)
•
CTG: Pair’s consistency group number
When the consistency group is not specified, dotted lines (---) display.
If you select the check box, the information displayed in the Business Copy Pair Operation
window is updated after the Detail dialog box closes. If you do not select the check box,
the information stays the same before when the dialog box is closed. Refresh the window after
this dialog box is closed.
check box
Updates the information in the Detail dialog box. Refresh
Closes the Detail dialog box. Close
Pairsplit-S dialog box
This dialog box lets you delete multiple Snapshot pairs.
62 Snapshot GUI reference
