Table 13 Cnt Ac-S/Cnt Ac-J Operations when P-VOL shared with SS S-VOL (continued)

Snapshot Pair Status

Continuous Access
Synchronous / Continuous
Access Journal Operations

PSUE

COPY(RS-R)

COPY(RS)

SMPL(PD)

PSUS

PAIR

COPY

Yes

No

Yes

Yes

Yes

Yes

Yes

Switch to remote site
(horctakeover)

* If you want to use a Cnt Ac-S or Cnt Ac-J S-VOL as a Snapshot P-VOL, the Snapshot pair must be created after the
Cnt Ac-S or Cnt Ac-J pair is created.

Following shows the correspondence table of the pair status display between RAID Manager and
Remote Web Console.

Table 14 Correspondence between RAID Manager and Remote Web Console

Remote Web Console pair display

RAID Manager pair display

SMPL

SMPL

COPY(PD)

COPY

COPY(PD)

RCPY

PAIR

PAIR

PSUS

PFUL

PSUS

PSUS

PSUS

PFUS

PSUS

SSUS

PSUE

PSUE

Figure 6 The combination use of 3DC multi-target configuration and Snapshot

The following explains about pairs in the figure.

Pair 1 is the Continuous Access Synchronous pair.

Pair 2 is the Continuous Access Journal pair.

Pair 3 is the Continuous Access Journal pair for delta resync.

Pair 4, pair 5, and pair 6 are Snapshot pairs.

NOTE:

You must create 3DC multi-target configuration for delta resync consisting of pair 1, pair 2,
and pair 3 before creating pair 5, which is a Snapshot pair. You do not need to create 3DC
multi-target configuration for delta resync consisting of pair 1, pair 2, and pair 3 before
creating pair 4, which is a Snapshot pair.

You must create 3DC multi-target configuration for delta resync consisting of pair 1, pair 2,
and pair 3 before creating pair 6, which is a Snapshot pair.

Continuous Access Synchronous or Continuous Access Journal
