Description

Item

Tier 3: Sets buffer space for new page assignment for tier 3 from 2% to 40%.
The default value is 2%.

This function can be set only when Multi-Tier Smart Pool is enabled.

*The items with asterisks require configuration.

Add button

When you click Add, the configured information is added to the right Selected Pools table.

Selected pools table

The following table lists the details of items.

Description

Item

Nickname and ID of the pool.

Pool Name (ID)

RAID level of the pool.

RAID Level

If multiple RAID levels exist in a pool, this field indicates that RAID levels are
mixed.

Maximum pool capacity.

Capacity

Shows the pool type.

Pool Type

For Thin Provisioning or Smart Tiers:

THP is displayed.

For Snapshot:

Snapshot is displayed.

Type and rpm of the Hard disk drive.

Drive Type/RPM

Create Pools wizard

77
