Table 17 Fields in the Detail dialog box (continued)
Descriptions
Items
Updates the information in the Detail dialog box.
Refresh button
Closes the Detail dialog box.
Close button
Monitoring S-VOL path information
You can view path information for the S-VOL.
To monitor S-VOL path information:
1.
In Remote Web Console, click Actions > Local Copy > Business Copy/Snapshot > Pair
Operation.
2.
In the Pair Operation window, select a pair in the volume list, right-click, and select S-VOL
Path command from the menu.
Figure 9 S-VOL Path Dialog Box
3.
In the S-VOL Path dialog box, check S-VOL information as desired. Fields are described below.
Table 18 Fields in S-VOL Path dialog box
Descriptions
Items
Path information for the selected pairs. P-VOL and S-VOL volumes are shown in the
AAA-BB-CCC(XX:YY:ZZ) format.
Pair Information box
•
AAA: Port ID (cluster name and channel number)
•
BB: Group number (G-ID) of host group
