Page 83

Description
Item
•
Type: Type of port (Serial).
•
Attribute: Port attribute. LCP is displayed.
Displays the following when Mfibre is selected in Type:
Port list (when Mfibre is
selected)
•
SLPR: SLPR number and SLPR name.
•
Port Name: Port name.
•
Type: Type of port (Mfibre).
•
Attribute: Port attribute. HTP or FNP is displayed.
•
WWN: WWN of the Mfibre port.
LUN Dialog Box
The LUN dialog box displays information about open-system volumes. For more detailed information
about the displayed items, see the HP XP24000/XP20000 LUN Manager User Guide.
Figure 41 LUN Dialog Box (Reports Display)
Description
Item
Allows you to display information about a particular SLPR when you select the SLPR from
this list. If you have logged in as a storage partition administrator, only information about
the allocated SLPR is displayed, and you cannot select other SLPRs from this list.
SLPR list
Select the port for which information is to be displayed from the list.
Port
SLPR number and SLPR name.
SLPR column
Port name.
Port Name
The group number of the host group.
Group ID
Reports Display Dialog Boxes
83
