Table 18 Available Configuration Values for the [LDEV] Tag
Column Item Available Value
1st, 11th (Index) Ldkc 00
2nd, 12th (Index) Cu
00 - FE. Set with hexadecimal numbers in one or two
digits.
3rd, 13th (Index) Ldev
00 - FF. Set with hexadecimal numbers in one or two
digits.
4th, 14th
Cmd. Dev
(Command Device)
Enable or Disable (The default when the spreadsheet is
exported)
ON or OFF are also available as the set value when you
write the spreadsheet.
5th, 15th
Cmd. Sec
(Command Device
Security)
Enable or Disable (The default when the spreadsheet is
exported)
ON or OFF are also available as the set value when you
write the spreadsheet.
6th, 7th,
16th, 17th
Blank
Error Check
First Error Check
The first error check is performed when the spreadsheet file is imported. The first error check verifies
that the spreadsheet is properly formatted. If there is an error, the spreadsheet is rejected, and an error
message is displayed. Errors detected at this first check include the following:
• The first row of the spreadsheet (the declaration line) is not correctly written, or the
stated program product is not installed. For more information on the declaration line, see
“ Spreadsheet Declaration ” on page 87.
• The spreadsheet file is not in text file format (the file is a binary file).
• There is no function tag in the spreadsheet. For more information on the function tag, see
“ Function Tags ” on page 87.
• The file name is incorrect (for example, the extension is not .spd, or the file name exceeds the
maximum number of letters).
• The number of letters in a row exceeds 200.
• The number of rows in a spreadsheet exceeds 400,000.
Second Error Check
In the second check, the spreadsheet settings are verified. Any errors found are displayed on the
Error Information list. This second check is performed before the Apply button becomes available.
Figure 48 on page 99 shows the flow of the second check.
The second error check consists of two different types of the checks. These checks are shown in
Figure 48 on page 99 as the Level 1 and Level 2. The Level 2 check is performed only when no error is
found by the Level 1 check. Each level of the check of the second error check detects the following errors:
• Level 1 check (the format and parameters are checked):
• A function tag is not supported.
• A setting value is incorrect or omitted.
• The setting range is incorrect. The correct ranges are as follows:
LDKC:00
CU:00 - FE
