Table 7 Port Serial Numbers and Port Names (4-port Fibre Channel Adapter)
Port
serial
number
Standard
mode
High Speed
mode or
Initiator/External
MIX mode
Port
serial
number
Standard
mode
High Speed
mode or
Initiator/External
MIX mode
0 CL1-A CL1-A 32 CL1-J CL1-J
1 CL3-A CL3-A [1-A 2nd] 33 CL3-J CL3-J [1-J 2nd]
2 - - 34 - -
3 - - 35 - -
4 CL1-B CL1-B 36 CL1-K CL1-K
5 CL3-B CL3-B [1-B 2nd] 37 CL3-K CL3-K [1-K 2nd]
6 - - 38 - -
7 - - 39 - -
8 CL1-E CL1-E 40 CL1-N CL1-N
9 CL3-E CL3-E [1-E 2nd] 41 CL3-N CL3-N [1-N 2nd]
10 - - 42 - -
11 - - 43 - -
12 CL1-F CL1-F 44 CL1-P CL1-P
13 CL3-F CL3-F [1-F 2nd] 45 CL3-P CL3-P [1-P 2nd]
14 - - 46 - -
15 - - 47 - -
16 CL1-C CL1-C 48 CL1-L CL1-L
17 CL3-C CL3-C [1-C 2nd] 49 CL3-L CL3-L [1-L 2nd]
18 - - 50 - -
19 - - 51 - -
20 CL1-D CL1-D 52 CL1-M CL1-M
21 CL3-D CL3-D [1-D 2nd] 53 CL3-M CL3-M [1-M 2nd]
22 - - 54 - -
23 - - 55 - -
24 CL1-G CL1-G 56 CL1-Q CL1-Q
25 CL3-G CL3-G [1-G 2nd] 57 CL3-Q CL3-Q [1-Q 2nd]
26 - - 58 - -
27 - - 59 - -
28 CL1-H CL1-H 60 CL1-R CL1-R
29 CL3-H CL3-H [1-H 2nd] 61 CL3-R CL3-R [1-R 2nd]
30 - - 62 - -
31 - - 63 - -
Note: The hyphen (-) indicates that the port is not available.
XP24000 LUN Manager User's Guide 69
