V
iewer
File
The
File menu is used to Open records , to
Reopen (
Open again) the most recently used records
and to
Save the currently open record as displayed .
With
Save time window as the measurement pa-
rameters of the displayed time window are saved .
(The measurement parameters of the hidden traces
are also saved) . For further options see
Cutter ->44 .
Templates help to standardise the displays, enable
easy repetition when reselecting the same sensors
and the same printing format .
Creating templates: Adjust the display with Graph
and
Configuration and save via File > Save as
template (file type: * .mse) .
Apply a template to the displayed record:
File > Use template then select the required tem-
plate (*mse) .
Export Time window as text exports the meas-
urement parameters of the displayed time window
in * .csv format . The measurement parameters of the
hidden traces are also exported .
The trace can be exported in
Bitmap (* . bmp) or as
JPEG forma .
Print preview opens a preview of the trace/graph .
Print opens the print dialog box .
Exit closes the Viewer . If changes were made the
user is asked whether the changes should be saved .
Note:
The program saves changes as “Template”
(* .mse) . The template is automatically saved in the
record’s directory . Template (* .mse) and record
(* .rog) have the same name .
Upon
Opening a record the Viewer searches for
the template associated with that record . Should the
template not be located in the same directory as the
record then the standard format will be opened .
