Setup
Basic settings
This page describes the most commonly used settings – the Basic settings . Infor-
mation on further settings can be found on the following pages .
• Complete the preparations (->33) .
• Start Setup (Setup symbol) .
• Edit the Basic settings according to your requirements .
• Transfer the new configuration and the start conditions to the logger with Write
basic settings .
Define the sensors from which the logger should record data, together with the storage
rate .
The 50Hz (3200 Hz) function is only available for the acceleration sensors (ACC) .
50Hz (3200 Hz)
Acceleration values are measured at 3,200 Hz and saved at a frequency of approx .
50 Hz following digital filtration . Energy consumption increases for 50Hz (3200 Hz)
measurements .
Exit setup
Read the information
and measurement
parameters
Freezes the selected
options in the Basic
settings and Limits
tabs so that these
can be transferred to
other logger units ->32
Currently no data is being recorded (inactive)
(active: data recording in progress)
Name of the
logger ->33
Overwrite oldest
measurement param-
eters when memory
is full
Transfers the configuration, the start condi-
tions and the PC time to the logger
Stop data recording
Conditional record-
ing of measurement
parameters ->31
->33
->33
Blue LED flashes during data re-
cording ( ->32)
->40
->39
Enter the main
storage rates
