ROTRONIC LOG-HC2 Universal Datalogger - Manual (Page 10)

Instructions
10
Overview
The logger is a miniaturised universal datalogger for measuring and recording dif-
ferent physical measurement parameters .
For further information, see data sheets .
The Logger PC program enables users to customise the way in which the log-
ger measures and records data according to their requirements . The integrated
clock (RTC) allows data from as many loggers as required to be synchronised and
merged into a single data record .
USB connection cable CD with LOG
software
Controls
Indicator LED’s
Blue: Record indicator ->32
Red: Alarm indicator ->31
Yellow: Battery charge indicator ->14
Light sensor*
Display
Analogue connections*, see page 17 for terminal
assignment
USB PC-Interface
Push button T1 / T2
Connections for external Rotronic sensors
*LOG-HC2-RO1 only
LOG-HC2-RO1
LOG-HC2-P1
Mains adapter
Power supply
connector
