24
Setup
Reader
V
iewer
Online
Preparation
Before using the LOG PC programs Setup, Reader and Online, the following
preparations must be completed:
• Use the USB connecting cable to connect the logger with the PC .
• Before first use: Using logger symbol open the logger program window, select
Settings > Logger .
• Select the rule by which the Setup, Reader and Online programs are to search
for the required logger* .
• Enter the path to the
directory .
• See following page for
template
• Select the required
language .
Logger program window
* One of the following windows will appear if a connection to a logger cannot be
established using the current rule .
During Setup:
Loader Dialog Starts the
Setup demo mode
Starts the
Loader dialog
(see screenshot left)
