Setup
Defining the logger display
Select Display and then click Read user settings at the bottom .
Define what the device should display following a power-on-reset under Start-
up . A group of measurement parameters 1 defined under Group indication, or
a single channel 2 can be displayed .
1
2
Transfer the desired settings to the device by clicking Write user settings .
Defining the group indication
Define which channels should be displayed together in one group indication un-
der Display > Group indication . 4 group indications each with 4 channels can
be shown . For each channel, the measurement parameter, limit L1 or limit L2 can
be displayed .
Transfer the desired settings to the
device by clicking Write user set-
tings .
Open group indication on the de-
vice: See „Logger display and log-
ger operation“ on page 13 .
