UPHOLSTERY TOOL
LEGEND SE 980059 06/19/03 5-48
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 78513 COMPLETE
1 09-805131 HOSE, VAC 1-1/4X10’ BLU
2 08-805243 CUFF, SWIV 1-1/4HX1-1/4T
3 10-805347 HOSE, 3/16X119-1/2 (1/8PX1/4FT)
4 13-806023 DSC, 1/8FC1/8FP SST
5 58-500639 UPHOLSTERY TL TRIGGER
6 00-000310 SCR, CAP 4-40 X7/32 SHCS SS
7 04-000282 SPRING, VAC ADJ BUTT
8 52-501624 BUTTON, VAC ADJ
9 52-501842 TOOL, UPHOLSTERY
10 61-950570 ASSY, UPHLST TL VLV
INCLUDES PARTS 20-26,
28, & 31- 37
11 560012 NIPPLE, 1/4 NPT QD
12 17-803010 CONN, 1/4P X 11/16-16M
13 17-803006 WASHER, NYLON
14 14-806512 STRAIRNER, JET 50MESH
15 17-803036 CONN, 1/4FPX11/16-16F BR
16 11-800404 NIP, 1/4X5 SST
17 52-501585 COUPLER, UPHLST TL
18 12-800065 CONN, 1/8P X 1/4T
19 08-805138 CUFF, 1 1/4H X 1 1/2T GRY
20 16-808229 HOLDER, VLV STEM-EXTRCTR VL
21 43-810063 O-RING, .551 ID .691 OD
22 16-808228 SEAT, EXTRCTR VLV
23 16-808189 STEM, EXTRCTR VLV
24 43-810064 BACK-UP, 250DIA
25 43-810062 O-RING, .144 ID .254 OD
26 16-808190 SPRING, EXTRCTR VLV
27 00-000306 SCR, 6-32 X 1 SCHD SS
28 17-803033 TIP, SPRY 80015X1/8P SST
29 58-500638 CSTG, TRIGGER CLMP
30 00-000307 SCR, CAP 6-32X3/8 SOCHD
31 52-501623 VALVE, UPHLST TL
32 52-501626 VALVE, ADJ-UPHLST TL VLV
33 43-810016 O-RING, 5/32IDX9/32OD VIT
34 43-807513 GASKET, UPHLST TL VLV
35 10-805348 HOSE, 3/16X6-1/2 (1/8P BS)
36 13-806030 DSC, 1/8MX1/8FP SST
37 00-000408 SCR, SET 3-32 X 1/4 SOCHD
- 48-941164 DECAL, UPHLST TL NOT SHOWN
- 66-808169 KIT, REPAIR-WAND VLV
NOT SHOWN
INCLUDES PARTS 20-22
& 24-26
