Prochem Legend SE AD - Manual (Page 56)

ENGINE
LEGEND SE 980059 12/02/03
5-6
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 40-902152 ENG, KOHLER 20HP
2 42-902299 KOH ELEM, AIR CLNR#470830
3 42-902297 KOH PMP, FUEL PULSE #2439316L P
4 42-902289 KOH SPK PLG #1213202
5 42-902296 KOH FLTR, FUEL #2505003
6 03-000065 CLAMP, HOSE #4 SST
7 09-805091 HOSE, FUEL 1/4 X 27 1/2
8 12-800062 PLUG, 1/2T
9 10-805291 HOSE, HP 3/8 X 10 (3/8 X1/2 FT)
10 42-902365 SUB 42-902396 KOH KIT, VO
11 42-902277 KOH FLTR, OIL #1205001
12 56-502090 MNFLD, ENG EXH
13 42-902212 ONAN GSKT, EXH #154-2747
14 44-802237 BELT, AX42 GOODYEAR MATCH
15 54-500412 KEY, 1/4 SQ X 1.88
16 52-501660 PULL, ENG
17 44-802182 HUB, P2X1-1/8
18 44-802240 BELT, 3V X265
19 00-000311 SCR, 1/4-20 X 1/2 SHCS SS
20 44-802311 BLET, AX29 GOODYEAR MTCH MKR
21 52-501661 PULL, OUTR ENG
22 00-000340 SCR, MACH 5/16-18 X 1” GR 8
23 12-800041 FTTG, BARB 1/8P X 1/4H
24 790605 EL, 90DEG 1/8 X 5/16HB
25 56-501857 BRKT, FUEL LINE
26 87083 WASHER, 5/16 SPLIT LOCK PLTD
27 57054 NUT, M8
28 790626 GSKT, EXHST, KHLR 25HP
29 42-902293 KOH CARB, #2485335S
- 42-902286 KOH SE, OIL PRESS NOT SHOWN
- 42-902287 KOH GSKT, CYL HD #2404108 NOT SHOWN
- 42-902359 KOH ASSY, VLV CVR #2475574 NOT SHOWN
- 42-902360 KOH ASSY, VLV CVR (OIL) NOT SHOWN
- 42-902291 KOH DRIVE PINION NOT SHOWN
- 42-902294 KOH KIT, CARB REP #2475703 NOT SHOWN
- 42-902295 KOH KIT, HIGH ALTITUDE (9840 FT) NOT SHOWN
