Prochem Legend SE AD - Manual (Page 74)

SOLUTION OUTLET
LEGEND SE 980059 07/23/02
5-24
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 11-800101 PLUG, 1/8P
2 12-800040 ELL, 1/8P X 1/4T BR
3 10-805357 HOSE, 3/16 X38 (1/4 FT BS) MET)
4 11-800342 CONN, 1/2P X 1/2FP BR
5 12-800391 UNION, CAPILLARY-THERM
6 35-900182 CONTR, TEMP 275 DEG
7 12-800065 CONN, 1/8P X 1/4T
8 10-805205 HOSE, 3/16 X 15-1/8 (1/4FT BS)
9 12-800329 CONN, 1/4P X 1/2T SST
10 31017 ELBOW, 1/4FPT X 1/4PT
11 22015 COUPLER, 1/4 QD
12 10-805376 HOSE, 1/2 X 14-1/2 (1/2FT BS)
13 12-800282 CONN, 3/8P X 1/2T BR
14 11-800276 ELL, 3/8 BR
15 02-000066 FLATWASHER, 1/4
16 87162 WASHER, 1/4 SPLIT LOCK
17 57006 NUT, 1/4-20 HEX
18 56-501910 BRKT, SOL OUT MTG
19 70105 SCR, 1/4-20 X 1.75 HHCS PLTD
20 15-808095 ASSY, CHK VLV
21 52-501621 MANIFOLD, CHK VLV
22 14-806549 SCREEN, CHECK VALVE
23 43-810053 O-RING, .676ID X .816OD
24 15-808094 VALVE, CHECK
25 11-800429 NIP, NEX 3/8 SST
26 52-502066 MANIFOLD, THERMOSTAT
27 56-501974 BRKT, THERM MANIFOLD MOUNTING
28 34-903019 SENDER, TEMP 140-320 DEG
29 00-000132 SCR, 1/4-20 X 1-1/2 HXHD
30 52-501680 FTTG, SENS SUPT TM
