Prochem Legend SE AD - Manual (Page 84)

AIR PUMP
LEGEND SE 980059 07/23/02
5-34
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 55-501700 TUBE, RT AIR PUMP
2 12-800358 CONN, 1/8P X 3/8T COMP
3 56-502090 MANIFOLD, ENG EXH
4 11-800118 BUSH, 3/8 X 1/8 BR
5 02-000066 FLATWASHER, 1/4
6 87162 WASHER, 1/4 SPLIT LOCK
7 57006 NUT, 1/4-20 HEX
8 56-501791 TEE, CAT AIR PUMP
9 55-501699 TUBE, L AIR PUMP
10 11-800341 ELL, ST 3/8 45DEG BR
11 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
12 12-800161 FTTG, BRB 3/8P X 1/2H BR
13 03-000246 CLAMP, HOSE #8 SST
14 39174 HOSE, WIRE BOUND X 23”
15 44-802240 BELT, 3VX265 GOODYEAR
16 70266 SCR, 3/8-16 X 1” HHCS GR5 PLTD DL
17 87171 WASHER, 3/8 FLAT
18 52-501647 PULLEY, AIR PUMP
19 41-809122 PUMP, AIR
20 56-502117 BRKT, AIR PUMP
21 56-502328 BRKT, LWR ARI PUMP LEGEND SE
22 87083 WASHER, 5/16 SPLIT LOCK PLTD
23 70262 SCR, M8 X 20HHCS PLTD
24 87163 WASHER, 3/8 SPLIT LOCK
25 57111 NUT, 3/8-16 HEX
