TECHNICAL SPECIFICATIONS
LEGEND SE 980059 07/23/02
3-1
ITEM DIMENSION/CAPACITY
Engine speed 2600 rpm (high speed in H.E. position)
1400 rpm (idle speed in Muffler position waster pump OFF.
Water pump rpm 1395 rpm
Vacuum pump rpm 3195 rpm
Water flow rate 3.5 GPM (maximum)
Water pump pressure 1000 PSI (maximum)
Vacuum relief valve 13” Hg (13” Legend Hg - SE)
Waste tank capacity 70 gallons (60 gallons to shut-off)
Console weight 640 lbs. (730 lbs. If mounted on water tank)
Console weight (with waste tank & accessories) 886 lbs (976 lbs. If waste tank is full)
(1467 lbs. If waste tank is full)
(1566 lbs. If auxiliary water tank is full)
TORQUE VALUES
Engine hub
264 inch lbs 22 foot/lbs
Vacuum pump hub 192 inch/lbs 16 foot/lbs
JET SIZING:
Prochem recommends floor tool tip sizing not exceed a total of “.045”. Using larger jet sizes on your
LEGEND SE may reduce cleaning temperatures.
Example: Tri-jet wand uses three 95015 jets (95° spray angle w/ 015 orifice).
015 x 3 = 045
Upholstery tool jet size: 80015
Stair tool jet size: 9502
