PRESSURE REGULATOR MANIFOLD
LEGEND SE 980059 11/07/02
5-28
REF
PART NO.
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
790106
ACCUMULATOR
2
87162
WASHER, 1/4 SPLIT LOCK PLTD
3
00-000210
SCR, 1/4-20 X 3/4 SOCHD
4
10-805294
HOSE, 3/16 X 11.5 (1/4FT BS)
5
12-800346
ADAPTER, 1/4T X 3/8P
6
11-800275
ELBOW, ST 3/8 BR
7
11-800345
PLUG, 1/4 SOCHD BRASS
8
12-800347
ELBOW, 3/8P X 1/2T 45° BR
9
10-805424
HOSE, HP 3/8 X 10.5
10
10-805275
HOSE, 1/2 X 19 (1/2 FT BS) MET
11
12-800282
CONN, 3/8P X 1/2 T BR
12
11-800224
PLUG, 3/8 SOCHD BR
13
09-805384
HOSE, WATER 5/8 X 16
14
03-000246
CLAMP, HOSE #8 SST
15
12-800345
FITTING, BRB 3/8P X 5/8H BR
16
11-800341
ELL, ST 3/8 45DEG BR
17
790067
REGULATOR, PRESSURE
18
11-800429
NIP, HEX 3/8 SST
19
790112
MANIFOLD, PRESS REG. 1/2 “ PORT
20
16-808201
CAT #33246 KIT, O-RING REP
21
16-808200
CAT #33147 KIT, VALVE REP
