OPERATION
LEGEND SE 980059 06/19/03
3-21
CLEANING
Observe the following guidelines, while cleaning:
1. Before proceeding make sure the nozzles are
functioning properly.
a) To check, hold the wand about one foot
above the surface to be cleaned and open
the wand valve. A full spray should be
observed from the cleaning nozzles.
b) If the nozzles are not showing a full spray
pattern, adjust nozzles for proper pattern,
clean, or replace nozzles, if required.
2. Normally, chemical is applied on the push stroke
of the wand when cleaning, and vacuuming is
done on the pull stroke. For heavily soiled
carpets the wand may be used in a scrubbing
manner, applying chemical in both push and pull
strokes. Always finish up an area with a vacuum
pull stroke.
3. When cleaning, keep the working opening
(mouth) flat on the surface being cleaned. Keep
the wand moving when the valve is open.
4. The unit will automatically shut-down when the
waste tank is full. This will prevent water being
drawn into the vacuum pump. If shut-down
occurs, empty the waste tank before proceeding.
NEVER dispose of waste in storm drains,
waterways, or onto the ground. Always dispose
of waste in accordance with Local, State, and
Federal laws.
UPHOLSTERY CLEANING
Upholstery Tool, Part #78513
1. Set temperature as desired and slow down
engine speed to minimize excess heat.
2. Slow engine speed down to minimize excess
heat.
3. Use one (1) "80015" spray tip in the tool.
4. Pressure adjustment below 300 PSI should be
made at the tool itself, by using the adjusting
knob located on the valve.
STAIR TOOL CLEANING
Stair Tool, Long, Part #78519
Stair Tool, Short, Part #78521
1. Set temperature as desired and slow down
engine speed to minimize excess heat.
2. Slow engine speed down to minimize excess
heat.
3. Use one (1) "9502" spray tip in your stair tool.
