BYPASS MANIFOLD
LEGEND SE 980059 07/23/02
5-22
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 10-805357 HOSE, 3/16 X 38 (1/4FT BS) MET
2 12-500040 ELL, 1/8P C 1/4T BR
3 56-501906 ASSY, BRKT, BYPASS MTG
4 12-800065 CONN, 1/8P X 1/4T
5 10-805130 HOSE, 3/16 X 13-1/2 (1/4FT BS)
6 87162 WASHER, 1/4 SPLIT LOCK
7 00-000132 SCR, 1/4-20 X 1-1/2 HXHD
8 15-808112 ASSY, BYPASS MNFLD
9 10-805130 HOSE, 3/16 X 13-1/2 (1/4FT BS)
10 70105 SCR, 1/4-20 X 1.75 HHCS PLTD
11 02-000066 FLATWASHER, 1/4
12 57006 NUT, 1/4-20 HEX
13 52-501659 MANIFOLD, BYPASS
14 52-501701 ORIF, BYP MNFLD
15 43-810053 O-RING, .676ID X .816OD
16 53-501523 CAP, CHK VALVE MANIFOLD STRNR
17 14-806552 SCREEN, BYPASS MANIFOLD
