HOSE ACCESSORIES
LEGEND SE 980059 06/19/03
5-40
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 12-800078 FITTING, BRB 2H BS PVC
2 08-805147 CUFF, 2”
3 10-805060 HOSE, VAC 2”X50’ W/ CUFFS & HOSE
4 56015 NIPPLE, 1/4 HEX
5 22015 COUPLER, 1/4 QD
6 56012 NIPPLE, 1/4 FPT QD
7 10-805108 HOSE, HP 1/4 X 50FT W/QD & VLVE
8 10-805077 HOSE, HP 1/4 X 50’
9 08-805155 GUARD, HOSE VINYL
10 15-808012 VALVE, BALL 1/4FP
11 43-810014 O-RING, 7/32ID X 11/32OD
12 43-810019 O-RING, 3/8 ID X 1/2 OD
13 11-800354 NIP, 1/2 X 3/8 HEX BR
14 10-805157 HOSE, WATER 1/2 X 50’
15 13-806009 DISCONNECT 3/8M X 3/8FP
16 10-805295 HOSE, WATER 1/2 X 50’
17 22015 COUPLER, 1/4 QD
18 10-805077 HOSE, HP 1/4 X 50’
19 08-805155 GUARD, HOSE VINYL
20 56012 NIPPLE, 1/4 FPT QD
21 10-805122 HOSE, HP 1/4 X 50FT W/QD
