Prochem Legend SE AD - Manual (Page 64)

WATER PUMP
LEGEND SE 980059 07/23/02
5-14
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 42-809238 CAP, OIL FILLER
2 42-809239 O-RING, OIL FILL CAP
3 43-807063 GASKET, OIL GAUGE
4 42-902380 GAUGE, OIL LEVEL
5 42-809401 COVER, CRANKCASE
6 42-809402 O-RING, CRANK CVR
7 42-809394 O-RING, BEARING CVR
8 42-809403 MANIFOLD, HEAD
9 42-809404 PLUG, VALVE
10 42-809406 BOLT, MNFLD HD M8 X 65
11 42-809405 RETAINER, SEAL
12 42-809407 RETAINER, PNLGR W/STUD
13 42-809408 PLUNGER
14 42-809249 WASHER, KEYHOLE M18
15 42-809381 SLINGER, BARRIER
16 42-809409 SEAL, OIL CRANKCASE
17 42-809410 KIT, SEAL
ORDER 1 EA. TO REPLACE
ALL SEALS
18 66-950441 KIT, VLV
ORDER 1 EA. TO REPLACE
ALL VALVES
