ENGINE EXHAUST HEAT EXCHANGER
LEGEND SE 980059 07/23/02
5-20
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 61-950628 ASSY, CAT HE INCLUDES PARTS 1-14
1 01-000271 NUT, 1/4-20 HXHD BR
2 52-501643 SHEILD, CAT HE
3 58-700028 PAD, CAT HT SHEILD
4 56-501759 CVR, CAT HE END BC
5 43-807086 GSKT, EXH FLG
6 57-520074 ASSY, COIL MOUNT & CASING
7 57006 NUT, 1/4-20 HEX
8 02-000044 LOCKWASHER, 1/4 SST
9 70015 SCR, 1/4-20 X 3/4 HHCS SS
10 52-501654 NUT, ADAPT BUSH
11 64-950546 ASSY, HIGH TEMP SHUTOFF
12 35-900184 SENSOR, TEMP 285DEG
13 52-501671 FTTG, TEMP SENS ADPT TM
14 12-800171 ELL, 1/2P X 1/2T BR
15 10-805376 HOSE, 1/2 X 4 1/2 (1/2 FT BS)
16 02-000274 LOCKWASHER, 5/16 (ALLEN SCREW)
17 00-000315 SCR, CAP 5/19-18 X 7/8 SOCHD
18 42-902212 ONAN CAKT, EXH #154-2747
19 10-805275 HOSE, 1/2 X 19 (1/2FT BS) MET
20 02-000066 FLATWASHER, 1/4
21 87162 WASHER, 3/8 SPLIT LOCK
22 00-000078 SCR, 1/4-20 X 1” HXHD GRD8
- 66-945532 KIT, EXH HE CORE
INCLUDES PARTS 3,5,6
AND 18
- 57-520070 HE, EXH CAT INCLUDES PARTS 4-10
