Prochem Legend SE AD - Manual (Page 82)

DIVERTER VALVE
LEGEND SE 980059 07/23/02
5-32
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000210 SCR, 1/4-20 X 3/4 SOCHD
2 00-000265 SCR, SET 1/4-20 X 1/4 SOCHD
3 00-000315 SCR, CAP 5/16-18 X 7/8 SOCHD
4 00-000317 SCR, CAP 10-32 X 1 1/4 SOCH
5 87031 NUT, 5/16-18 HEX
6 57113 LOCKNUT, 5/16-18 HEX NYLOCK
7 01-000301 LOCKNUT, 10-32 SS
8 87162 WASHER, 1/4 SPLIT LOCK
9 87083 WASHER, 5/16 SPLIT LOCK PLTD
10 02-000066 FLATWASHER, 1/4
11 02-000274 LOCKWASHER, 5/16 (ALLEN SCREW)
12 31-900027 TERMINAL, INS DCS 1/4F 14-16W
13 36-900182 ROTARY SOLENOID
14 42-902212 GASKET, ONAN
15 43-807501 GROMMET, 1/2ID X 7/8OD
16 50-502158 PLT, ROTARY
17 52-502067 LINK, SOL CONN-FEM
18 52-502068 LINK, DIVERTER
19 56-502541 ROD, DIVRTR CONN
20 61-950885 VALVE, EXH DIVERTER
