TEMPERATURE SOLENOID & BYPASS VALVE
LEGEND SE 980059 07/23/02
5-30
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 12-800088 TEE, ADPT 1/8FP X 1/8P X 1/4T
2 12-800040 ELL, 1/8P X 1/4T BR
3 10-805000 HOSE, 3/16 X 9 (1/4FT BS)
4 15-808107 VALVE, METER 1/8FP (BYPASS)
5 12-800065 CONN, 1/8P X 1/4T
6 10-805204 HOSE, 3/16 X 23 (1/4FT BS)
7 31-900028 TERM, INS DSC 1/4M 14-16W
8 31-900027 TERM, INS DSC 1/4F 14-16W
9 15-808105 VALVE, SOLENOID 1/4F X 1/4F
10 11-800039 BUSH, 1/4 X 1/8 BR
11 87165 WASHER, #10 SPLIT LOCK
12 00-000065 SCR, 101-32 X 3/8” PNHD
13 02-000066 FLATWASHER, 1/4
14 87162 WASHER, 1/4 SPLIT LOCK
15 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
16 50-501721 BRACKET, SOLENOID
17 12-800031 ELL, 1/4P X 1/4T BR
18 10-805311 HOSE, 3/16 X 10.5 (1/4 FT BS)
