WATER PUMP
LEGEND SE 980059 07/22/03
5-12
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 10-805424 HOSE, HP 3/8 X 10 1/2”
2 12-800225 ELL, 3/8P X 1/2T BR
3 41-809153 PUMP, WATER CAT 3CP1140
4 11-800224 PLUG, 3/8 SOCHD BR
5 87171 WASHER, 3/8 FLAT
6 87163 WASHER, 3/8 SPLIT LOCK
7 57111 NUT, 3/8-16 HEX
8 12-800060 CONN. 1/4P X 1/4T BR
9 10-805316 HOSE, 3/16 X 5 (1/4FT BS) MET
10 12-800029 PLUG, 1/4T BR
11 11-800342 CONN, 1/2P X 1/2FP BR
12 02-000066 FLATWASHER, 1/4
13 89162 WASHER, 1/4 SPLIT LOCK
14 70260 SCR, M6 X 1 X 16MM HHCS
15 36-900140 CLUTCH, ELC WTR PUMP CAT
16 44-802311 BELT, AX29 GOODYEAR MTCH MKR
17 31-900185 CONN, BULLET M (.156)
18 56-502248 BRKT, PUMP ADJ
19 11-800069 PLUG, 1/2 SOCHD BR
20 00-000277 SCR, MACH 6MM X 14MM
21 00-000336 SCR, CAP 3/8-16 X 3 ALL THD
22 10-805300 HOSE, 3/16 X 45” HP W/1 1/4FT
23 12-800040 ELL, 1/8P X 1/4T BR
24 41-809158 PUMP, CHEM (O-RING CAP)
25 52-809125 ADPT, CAT CHEM PUMP
26 52-809123 RETAIN, VALVE SPRING
27 09-805363 HOSE, BRD 5/16 X 52
28 03-000065 CLAMP, HOSE #4 SPOTTER SST
29 12-800093 FTTG, BRB 1/8P X 5/16H
30 11-800014 ELL, STREET 1/8 BR
31 39619 HOSE, WTR 3/4 X 10”
32 03-000113 CLAMP, HOSE #12 SST
33 12-800278 FTTG, BRB 1/2P X 3/4H BR
34 11-800041 ELL, STREET 1/2 BR
- 05-008016 OIL, CAT-WTR PUMP NOT SHOWN
