WASTE TANK
LEGEND SE 980059 07/23/02
5-36
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 61-951175 ASSY, LID WST TNK
2 56-501788 LID, WST TNK
3 67006 RIVET, 3/16 OD X 5/8 AL
4 46-802510 LATCH, DRAW 2-7/8 SST
5 48-941297 DECAL, ARROW-WST TANK LID
6 43-807094 GASKET, WST TNK LID
7 56-501793 STRAINER BOWL
8 56-501829 TANK, WST BLUE
8A 56-501973 TANK, WST
FOR UNITS MOUNTED ON
AUXILIARY WATER TANK
9 31016 ELBOW, 1/4 NPT STREET
10 12-800092 FTTG, BRB 1/4 X 5/16H BR
11 03-000065 CLAMP, HOSE #4 SST
12 09-805099 HOSE, BRD 5/16 X 40
13 03-000054 CLAMP, HOSE #32 1.5625/2.5 SST
14 09-805415 HOSE, INT VAC 2 X 12”
15 61-950621 ASSY, LVL SNS SHTOF SW
16 09-805341 HOSE, VAC 2.88 X 25.0 BLK
17 03-000112 CLAMP, HOSE #48
18 14-806518 STRAINER, WASTE TANK 2-1/2”
19 11-800402 PLUG, 1-1/4 HXHD PVC
20 09-805332 HOSE, 2.0 X 120.0 BLK
21 15-808080 VALVE, BALL PVC 1-1/2FP
22 12-800357 FTTG, BARB 1-1/2P X 2H
23 02-000066 FLATWASHER, 1/4
24 00-000078 SCR, 1/4-20 X 1” HXHD GRD8
25 03-000242 CLAMP, CABLE 3/4ID 1/4BLT
26 87162 WASHER, 1/4 SPLIT LOCK
27 57006 NUT, 1/4-20 HEX
28 56-501779 TRAY, BATTERY
29 50-501697 SPACER, BAT SHLF MTG
30 64-950514 CABLE, BATX101” RED
31 47-700007 SHIELD, BAT MT HT
32 36-900056 BATTERY
33 64-950515 CABLE, BATX111” BLK
34 31-900179 COVER, BATTERY TERMINAL
35 56-500188 COVER, BATTERY
36 00-000167 SCR, 1/4-20 X 6” HXHD
- 05-008002 ADHESIVE, GASKET NOT SHOWN
