INSTALLATION
LEGEND SE 980059 07/23/02
3-5
All units must be bolted to the floor of the
vehicle by a PROCHEM DISTRIBUTOR.
LIFTING THE UNIT ONTO THE VEHICLE
Since the Prochem LEGEND SE console weighs
approximately 640 lbs. (730 lbs. if mounted on water
tank), we recommend using a fork lift to lift the unit
onto the vehicle. Position the forks under the unit
from the front and make CERTAIN that the forks are
spread to the width of the base.
POSITIONING THE UNIT IN THE
VEHICLE
Because vehicles vary in size and openings,
individuals have their own preference as to where
they want their units installed. We strongly
recommend a side door installation for the
LEGEND SE and DO NOT recommend a rear door
installation.
1. Enough space should be provided to assure
adequate engine ventilation and room for
service and maintenance.
2. The unit with waste tank and accessories must
NOT exceed the vehicle's axle weight limit.
3. DO NOT position the console closer than 12"
from the bottom of the driver and passenger
seats.
NOTE: For individuals who wish to make an
engineering layout prior to positioning the unit,
refer to Figure 2 for waste tank and console
dimensions.
BOLTING DOWN THE UNIT AND WASTE
TANK
NOTE: When positioning the waste tank with
respect to the console, hook up the vacuum
hoses to the waste tank. This will ensure that the
waste tank is positioned correctly. Once the unit
and waste tank are positioned in the vehicle in
the desired location, you may proceed.
Before drilling any mounting holes in the vehicle
floor, make certain that when drilling, you will
not do any damage to the fuel tank, fuel lines, or
any vital component which might affect the
operation or safety of the vehicle.
1. Using the console and waste tank mounting
holes as a template, drill six 13/32" diameter
holes for mounting the console and six more
13/32" diameter holes for mounting the waste
tank.
2. Using the installation hardware kit:
a) Insert six 3/8-16 x 2" hex head cap screws
with flat washers through the mounting
holes in the Prochem LEGEND SE
console, and six 3/8-16 x 2" hex head cap
screws with flat washers through the
mounting holes in the waste tank.
b) Install the mounting plates underneath the
vehicle floor.
c) Screw the 3/8-16 hex head locknuts on
the mounting screws and tighten them
until the console and the waste tank are
firmly secured to the vehicle floor.
