VACUUM EXHAUST HEAT
EXCHANGER AND SILENCER
LEGEND SE 980059 07/23/02
5-18
1 PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 56-501928 EXH OUTLET
2 03-000081 CLAMP, MFLR 1-1/2 ZNC PL
3 57-520099 MUFFLER, ENG EXH VERSION D (FLNG)
4 02-000066 FLATWASHER, 1/4
5 87162 WASHER, 1/4 SPLIT LOCK
6 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
7 03-000112 CLAMP, HOSE #48
8 09-805344 HOSE, INT VAC 2.88 X 3.0 BLK
9 56-501892 HOUSING VAC HE
10 57-520082 MUFFLER, VACUUM
11 09-805396 HOSE, INT VAC 2.88 X 2.0 BLK
12 00-000078 SCR, 1/4-20 X 1” HXHD GRD8
13 43-807080 GASKET, VAC HE INLET
14 58-700027 PAD, VAC HE CORE
15 09-805368 HOSE, WTR 5/8 X 29
16 03-000246 CLAMP, HOSE #8 SST
17 61-950696 VAC HE CORE
18 09-805384 HOSE, WTR 5/8 X 16
19 43-807081 GASKET, VAC HE CORE
