VACUUM PUMP
LEGEND SE 980059 07/23/02
5-10
REF
PART NO.
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
41-905021
PUMP, VAC 4M-L
2
54-501593
NIP, VAC EXH OUTL
3
03-000112
CLAMP, HOSE #48
4
09-805396
HOSE, INT VAC 2.88 X 2.0 BLK
5
54-501735
KEYSTOCK, 3/16 X 1 5/8
6
44-802237
BELT, AX42 GOODYEAR MATCH
7
44-802218
PULLEY, 2TA46
8
44-802204
HUB, P1 X 3/4”
9
00-000340
SCR, MACH 5/16-18 X 1” GR5
10
87171
WASHER, 3/8 FLAT
11
87163
WASHER, 3/8 SPLIT LOCK
12
70266
SCR, 3/8-16 X 1” HHCS GR 5 PLT DL
13
12-800101
ELL, 1/4FP X 1/4 POLY BR
14
18-808525
GAUGE, VACUUM 30” HG
15
19-800075
CUP, OIL FILL 1/8P
16
12-800059
CONN, 1/8P X 1/4 POLY BR
17
09-805224
TUBING, IMPOL 1/4 X 50
18
09-805440
TUBING, IMPOLENE X 35”
19
02-000057
FLATWASHER, 1/2” HEAVY
20
00-000323
SCR, 1/2-13 X 3 1/2 HHCS FULL THD
21
70357
SCR, 1/2-13 X 3 FULL THREADS
22
56-502324
BRKT, VAC ADJ LEGEND SE
23
61-950451
ASSY, VAC REL VLV
24
09-805341
HOSE, VAC 2.88 X 25.0 BLK
25
57114
NUT, 7/16-14 HEX
26
04-000091
SPRING, VAC REL VLV
27
52-501573
ELL, VAC REL VLV
28
56-501615
STEM, VAC REL VLV #4 VAC
29
43-807074
DIAPHRAGM, VAC REL VLV
-
05-008039
OIL, AEON PD (28G24 SUTORBILT)
NOT SHOWN
-
05-008032
GREASE, MA3830150
NOT SHOWN
