4 Communication
BU 0590 GB-0312 Subject to technical amendments 31
4.2.4.2 Writing the frequency inverter parameter P102 Index 1 (start-up time)
Data record 101 is used:
Field Data size Byte Date Explanation
Order label
+
Parameter number
2 Byte
2
02 h
+
44E h
_________
244E h
Read parameter value (see Section 4.2.3)
+
Parameter number P102 (+1000) = 44E h
Parameter index
(Data record)
2 Bytes 3
4
01 h
00 h
Parameter sub-index (see Section 4.2.3.2)
Parameter value 4 Bytes 5
6
7
8
00 h
00 h
00 h
FA h
The time 2.5s (250 = FA h) is to be set
Table 27 Example telegram for reading parameter P102[-02]
S7 Code example:
CALL "WRREC" , DB53

WriteRequest
REQ :=#bStart
ID :=DW#16#7FC

Diagnosis address
INDEX :=101

Data record 101
LEN :=8

Length: 8 Bytes
DONE :=#bEnde
BUSY :=#bBusy
ERROR :=#bError
STATUS:=#wStatus
RECORD:=P#DB10.DBX0.0 BYTE 8

Data: 24h, 4Eh, 01h, 00h, 00h, 00h, 00h, FAh
CALL "RDREC" , DB52

ReadResponse
REQ :=#bStart
ID :=DW#16#7FC

Reference
INDEX :=101

Data record 101
MLEN :=8
VALID := …
BUSY := …
ERROR := …
STATUS:= …
LEN := …
RECORD:=P#DB10.DBX12.0 BYTE 8

Response: 14h, 4Eh, 01h, 00h, 00h, 00h, 00h, 00h
