May, 2013 Page 41 of 52 949-1194 Rev. 7
ERROR MESSAGES
Any error message may be cleared by using the ‘Global Reset’ by pressing and
holding the INDEX & ENTER keys for five seconds.
Display
A r E A
(Alternates
with PV)
A r E A
Meaning
This message appears
if the ambient
temperature of the
control approaches
the ends of tolerance.
This message
appears if the
ambient temperature
of the control is out of
range or RJC sensor
is broken
SP Outputs
Set point
outputs
active Alarm
active
Set point
outputs
active Alarms
active
Action Required
Correct the ambient temperature
conditions. Ventilate the area of the
cabinet or check for clogged filters. If
internal temperature sensor
(RJC located in terminal 2) is broken,
return to factory for service.
Correct the ambient temperature
conditions. Ventilate the area of the
cabinet or check for clogged filters.
If internal temperature sensor is
broken, return to factory for service.
