System Settings
To change system settings, select the System Settings tab on the left-hand side . A screen similar to the one below appears:
1 . Change any settings according to the tables
below .
2 . Click SAVE to save your changes or CANCEL
to discard the changes and return to the Main
screen .
System Settings Fields
Location Location is set as a factory default and cannot be changed by the user .
Skip Failed DK in Init The system can be configured to skip a keypad that it cannot communicate with and
continue with the initialization process . To activate this, check the box next to Skip Failed DK
in Init .
Decimal Point Select a period or comma as the decimal point .
Firmware Version Select the firmware version your master and Dispense Keypad is using . Version 1x can
support 99 meters, version 2x and version 3x for 2 .4 GHz radios can support up to 250
meters .
Auto Log Off If you would like the software to automatically log off the PC user after a specified period of
time, check the box next to Auto Log Off and chose the time (in minutes) you would like the
PC user to remain idle before being logged off .
Email Completed WO Work Orders may be emailed or printed upon completion . To set this up, check the box next
to the corresponding text . There are two buttons in the Functions section .
Use the Printer Settings button to select a printer that is available on your network . Use the
Page Setup to set up paper formatting information . Enter text that you want to appear on
the printout in the work order message box . Make the appropriate changes, then click SAVE
to save your changes and exit the printer settings . The CLEAR button will reset all of the
information on the form .
Print Completed WO
Allow Users to Delete WOs To allow dispense users to delete work orders, check the box next to the
Allow Users to Delete WOs field .
Allow Users Fluid Delivery To allow dispense users to enter a fluid delivery, check the box next to the
Allow Users Fluid Delivery field .
* Auto Override Enables the Dispense Keypad to automatically enter System Override mode when
communication is lost to the Master Keypad .
* Available for v3 .x firmware only .
Fluid Managment System, FMS-3 2.4 GHz RF High-End Software v3.4.1
Page 44 July 2014
