Buzzer
The buzzer beeps each time you press a button . You can turn off the sound . See Global Keypad Settings .
Auto Override
Activates the system Auto Override feature in all keypads so users can dispense WOs when the Master Keypad is not
operational . No supervisor intervention is required . Available with v3 .X firmware only . After five failed MK communication
attempts, the Auto Override feature automatically puts the keypad in system override mode .
1 . Use the SCROLL key to move the cursor to either YES or NO .
2 . Press ENTER .
Batch Quantity Locked
With the Batch Quantity Locked, you cannot change the batch quantity
that was entered on the work order . If the work order has a batch
quantity of zero, you can change the batch quantity .
Hose ID First
Used for HOST communication option only .
Selected product ID will be sent to the HOST .
Delete Prepared WOs (MET) Menu
Work orders that have been entered at a keypad are stored until they are picked up by the appropriate meter (by pressing
RESET at the meter) . Meanwhile, the meter is locked for other dispenses .
Select
CNF MET REP 190
The MET menu is used to delete prepared work orders and release the
meter for new work orders .
1 . Use the Scroll key to move the cursor to either YES or NO .
2 . Press ENTER .
Reset All Hoses
Press Enter
3 . Press ENTER .
Auto Override
YES / NO
Batch Qty Locked
YES / NO
Hose ID First
YES / NO
Init All Hoses
YES / NO
