Meter Selection
Enter a preset meter (hose) ID for the product .
Enter Hose
- - -
5 . Enter a preset meter (hose) ID for the fluid product you want and
press ENTER .
• Only meters that are assigned to the current keypad can be selected .
• In the operation modes WO Validation HOST or WO Validation PC the system will check if the product you entered is assigned to this work
order .
Display Fluid
Fluid
Product Name
6 . The chosen fluid type is displayed for three seconds .
Product Quantity
Quantity
----
7 . Enter the desired quantity and press ENTER .
Optionally, the quantity assigned to this WO is shown .
• The quantity can be chosen between 0 .0…99 .9 and 100…999 units of measure .
• The preselection can be made with one decimal place .
• For quantities more than 100 units of measure, the meter counts down toward zero .
• A quantity of 0 .0 will deactivate the preselection on the RF meter . The RF meter will not latch and the user is required to hold the
trigger in the open position to dispense fluid . The user must press RESET on the RF meter to complete the dispense operation and
communicate the dispense order result to the keypad .
Dispense Confirmation
Enter for
Dispense
8 . Press ENTER to dispense the fluid .
The work order is now ready for being picked up by the RF meter (see
RF Mode, Standard Preselection Mode) .
