Badger Meter Fluid Management System - Manual (Page 17)

Radio Power
Select
ADR NWK PWR STA
1 . Use the SCROLL key to move the cursor to PWR .
2 . Press ENTER to display the Radio Power Level screen .
RADIO PWR LEVEL
20 dBm
3 . Press ENTER to return to the selection screen .
Radio Status
The Radio Status options are:
•
NWK CONNECTED – The network is connected and operational .
• SERIAL ERROR – There is a radio communication error on the serial bus between the keypad and the radio .
Select
ADR NWK PWR STA
1 . Use the SCROLL key to move the cursor to STA .
2 . Press ENTER to display the Radio Status screen .
RADIO STATUS
NWK CONNECTED
3 . Press ENTER to return to the selection screen .
Change Channel
The Change Channel option is used to select a different RF channel if the current channel is noisy .
Select
CHA ... ... ...
1 . Use the SCROLL key to move the cursor to CHA .
2 . Press ENTER to display the Radio Network screen .
RADIO NETWORK
CHANNEL CHANGE
3 . Press ENTER to select a new channel .
RADIO COMMAND
SUCCESS
4 . The screen displays the radio command status .
User Manual
Page 17 July 2014
