Network Connect (CON) Menu

The Network Connect forces the keypad to connect to a new Master Keypad network . This option is used when:
•

Replacing the Master Keypad .

•

Moving the Dispense Keypad if the Dispense Keypad does not automatically find the new network .

Select

ADR NWK PWR STA

Select

CON ... ... ...

1 . Use the SCROLL key to move the cursor to CON .

2 . Press ENTER to display the Radio Network screen .

RADIO NETWORK

CONNECTING

3 . Press ENTER to display the Radio Status screen .

RADIO STATUS

NWK CONNECTED

4 . The screen displays the radio connection status (NWK CONNECTED

or NWK DOWN) .

System Override (SYS) Menu

Select

LNK RAD SYS ...

The System Override Menu is used to override verification of the Master

Keypad .

System Override

YES / NO

1 . Use the SCROLL key to move the cursor to YES .

2 . Press ENTER .

System Override

The screen verifies that System Override is On .

Fluid Managment System, FMS-3 2.4 GHz RF High-End Software v3.4.1
