Badger Meter Fluid Management System - Manual (Page 12)

Configuration (CNF) Menu
Select
INI CNF DK REP
The CNF menu is used to set the system’s operation modes and
archiving methods .
Order List
Not Empty
If you see the message “Order List Not Empty," you have to clear the
transactions in the Master Keypad (CNF Menu) .
Clear Transacts
YES / NO
Use the SCROLL key to move the cursor to either YES or NO and
press ENTER .
Confirm Clear
YES / NO
Use the Scroll key to move the cursor to either YES or NO and
press ENTER .
System Reset
The System Reset allows a supervisor to reset all configuration parameters to default values .
System Reset
YES / NO
1 . Use the SCROLL key to move the cursor to either YES or NO .
Confirm Reset
YES / NO
a . If you select YES, the keypad asks you to Confirm Reset .
b . If you select NO, the keypad advances .
3 . Press ENTER .
Keypad Timeout
• Timeout parameter corresponds to the time it takes to validate after all dispense order data has been entered . If the Enter
button is not pressed within the time allocated, the keypad display goes back to initial menu and the input data is erased .
• The Keypad Timeout is between zero to 255 seconds (0 = no timeout) and the default for this feature is 10 seconds .
Keypad timeout
16-
1 . Press the BACKSPACE key to erase the current setting .
2 . Type in the new setting .
3 . Press ENTER to advance .
Buzzer
This screen provides a user with the option to have a beep on every key entry . The default is YES .
Buzzer
YES / NO
1 . Use the SCROLL key to move the cursor to YES or NO .
2 . Press ENTER to advance .
Fluid Managment System, FMS-3 2.4 GHz RF High-End Software v3.4.1
Page 12 July 2014
