Reports (REP) Menu
•
Connect a printer or a PC (Terminal program) to the serial printer port (RS232) .
• Settings are 9600 Baud, Data Bits 8, Stop Bits 1, Parity ODD .
• Reports are automatically stored in the data logger (RF-memory) at the Master Keypad .
Select
CNF MET REP 190
To use this feature, you must the select External Printer option in
the CNF menu.
The REP menu is used to print reports from an external printer .
Select Report->
INI CNF MET WO
Use the SCROLL key to move the cursor to the report you want to print
and press ENTER .
The options are:
INI Initialization USR Sort list by user
CNF Configuration PRO Sort list by product
MET Sort list by meter HOS Sort list by hose (meter)
WO Sort list by work order TNK Sort list by tank
Select Report->
USR PRO HOS TNK
190 (Internal Ticket Printer) Menu
Use this menu to print the configuration and status reports from the internal printer FT 190 (optional) .
Select
CNF MET REP 190
To use this feature, you must the select Internal Printer option in
the CNF menu.
The 190 menu is used to print reports from an internal printer .
Select Report->
INI CNF MET WO
Use the SCROLL key to move the cursor to the report you want to print
and press ENTER .
The options are:
INI Initialization MET Sort list by meter
CNF Configuration WO Sort list by work order
