Radio (RAD) Menu
The RAD menu screens are:
•
Address (ADR) toggles the display between the Radio Address and the Radio Prefix screens .
• Network (NWK) allows you to select the Radio Network .
• Power (PWR) displays the radio’s transmit (Tx) output power .
• Status (STA) displays the Radio Network Status .
• Change Channel (CHA) allows you to select a different RF channel .
Select
INI CNF MET REP
1 . Use the SCROLL key to move the cursor to REP .
Select
RAD ... ... ...
2 . Press SCROLL two more times to move the cursor to the RAD
selection .
3 . Press ENTER to display the RAD screen .
Select
ADR NWK PWR STA
4 . Use the SCROLL key to move the cursor to the information you
want to display .
5 . Press HOME to go back to the default screens .
Radio Address/Radio Prefix
Once you select ADR, you can use the Scroll key to toggle between the Radio Address and the Radio Prefix screens .
Select
ADR NWK PWR STA
1 . Use the SCROLL key to move the cursor to ADR .
RADIO PREFIX
00:0D:6F:00
2 . Press SCROLL again to display the Radio Prefix screen .
RADIO ADDRESS
01:80:A5:63
3 . Press ENTER to display the Radio Address screen .
4 . Press ENTER to return to the selection screen .
Radio Network
The Radio Network default is zero . You need to change this setting only if you have multiple RF FMS systems . All
RF Meter/Hose Radio Network settings must match the Master Keypad and Dispense Keypad settings .
Select
ADR NWK PWR STA
1 . Use the SCROLL key to move the cursor to NWK .
2 . Press ENTER to display the Radio Network screen .
RADIO NETWORK
0--
3 . Press ENTER to return to the selection screen .
