11.9 Miscellaneous
Text 1 Description Range Def.
Aux General
Fkey Function of front panel key H. 0: no function
1: automatic / manual
2: Wext / Wint
1
Blck1 EBloc extended operating level 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
HBloc auto/man- key 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
CBloc controller off 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
WBloc setpoint 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
Blck2 PBloc programmer preset 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
RBloc programmer run/stop/reset 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
OBloc selftuning 0: free 1: blocked 2: blocked by di1 3: blocked by di2 0
11.10 Signals
Signl Description Range Def.
Setpt Setpoint signals
Wint Internal set-point
Wext External set-point
dWext External correction
dW Set-point offset -99,9 ... 999,9 0
Wsel Min/max set-point
Contr Controller signals
Y Correcting value
Yp Position feedback
xw Control deviation
x1 Main input x1
x2 Auxillary input x2
x3 Auxillary input x3
z Auxillary variable
OVC External correcting variable limiting
xeff Effectiv process value
Input Input signals
INP1 Input 1
INP1r Raw measure 1
...
INP6
Input 6
INP6r Raw measure 6
Prog Programmer signals
Wp Programmer setpoint
tBrut Brutto time (inc. all pause times)
tNet Netto time (without pause times)
tRest Rest time
PNr Programmer no. 1 ... 3 1
Clock Current time
Parameters
